Isuzu Trooper II (1992-2002) mirror folding switch Wiring diagrams
This page contains all the electrical diagrams for the component. mirror folding switch, in which he is found in the car Isuzu Trooper II (1992-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
mirror folding switch wiring diagram (1 of 3)
ACCESSORY METER
ANTI-THEFT, KEYLESS ENTRY CONTROL UNIT
B-12
B-20
B-24
B-29
B-30
B-31
B-32
B-36 B-37
B-52
B-55
B-56
B-57
BLK WIRE
COMBINATION SWITCH
D-21
D-22
D-26
D-27
DASH FUSE BOX (BEHIND LEFT KICK PANEL) POWER WINDOW RELAY HEATER, A/C RELAY
DRIVER'S POWER SEAT SWITCH
DRIVER'S SEAT BELT SWITCH
DRIVER'S SEAT HEATER SWITCH
DRIVER'S SEAT RECLINE MOTOR, SWITCH
DRIVER'S SEAT TILT MOTOR, SWITCH (FRONT)
DRIVER'S SEAT TILT MOTOR, SWITCH (REAR)
F-4
FUEL PUMP
FUEL TANK UNIT
H-46
H-47
L-1
L-5
LEFT REAR DOOR LOCK ACTUATOR/ SWITCH
LEFT REAR POWER WINDOW SWITCH
MIRROR CONTROL SWITCH
MIRROR DEFOGGER SWITCH
MIRROR FOLDING SWITCH
POWER/ WINTER SWITCH
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SEAT HEATER SWITCH
RIGHT FRONT SEAT RECLINE MOTOR, SWITCH
RIGHT FRONT VANITY MIRROR LIGHT LEFT FRONT VANITY MIRROR LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ SWITCH
RIGHT REAR POWER WINDOW SWITCH
S-5
SHIFT LOCK CONTROLLER
SUNROOF CONTROL UNIT MOTOR
SUNROOF SWITCH
T-10
T-11
T-12
T-3
T-5
T-8
W/SUNROOF
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> MIRROR FOLDING SWITCH
mirror folding switch wiring diagram (2 of 3)
24 7 I-9 METER ASSEMBLY
ACCESSORY METER
ANTI-THEFT SYSTEM
ASHTRAY ILLUMI- NATION
BLK WIRE
CIGARETTE LIGHTER ILLUMINATION
CLOCK
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH
F-12 TAIL FUSE
FOG LIGHT SWITCH
FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
GLOVE BOX ILLUMI- NATION
GRN WIRE
GRN/RED WIRE
HAZARD WARNING SWITCH
HEAD PARK
HOT AT ALL TIMES
I-15
I-32
I-32 AUTOMATIC HEATER A/C CONTROL UNIT SOLID STATE
I-9 8 25
ILLUMINATION
ILLUMINATION CONTROLLER
LEFT FRONT VANITY MIRROR LIGHT
LIGHTING SWITCH
M/T A/T
METER ASSEMBLY
MIRROR CONTROL SWITCH
MIRROR DEFOGGER SWITCH
MIRROR FOLDING SWITCH
OFF
POWER/ WINTER SWITCH (2 BULBS)
RADIO OR RADIO/ CD PLAYER SWITCH SOLID STATE
REAR DEFOGGER SWITCH
REAR WIPER/ WASHER SWITCH
RED WIRE
RED/BLK WIRE
RIGHT FRONT VANITY MIRROR LIGHT
S MODEL LUXURY,
SHIFT LEVER LIGHT
SOLID STATE
TAILLIGHT RELAY
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> MIRROR FOLDING SWITCH
mirror folding switch wiring diagram (3 of 3)
BLK WIRE
BLU WIRE
C-11 (AUDIO [ACC]) MIRROR FUSE
CLOSE
CLOSE OPEN
DASH FUSE BOX (BEHIND LEFT KICK PANEL)
DEFOGGER SYSTEM
DOWN
FOLD RETURN
FOLDING MOTOR
GRN WIRE
GRY WIRE
HOT IN ON OR ACC
ILLUMINATION
LEFT
LEFT DOOR MIRROR
LEFT/RIGHT MOTOR
MIRROR CONTROL SWITCH
MIRROR CONTROL SWITCH INTERNAL SWITCH POSITIONS
MIRROR DEFOGGER
MIRROR DIRECTION SELECTED
MIRROR FOLDING SWITCH
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT
RIGHT DOOR MIRROR
RIGHT LEFT
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH 3 MASTER SELECTOR SWITCH
SWITCH 4
UP/DOWN MOTOR
WHT WIRE
Go to component -> Power mirror circuit -> MIRROR FOLDING SWITCH
