Isuzu Trooper II (1992-2002) mirror defogger switch rear window defogger relay power window relay Wiring diagram
This page shows the only wiring diagram for the component.mirror defogger switch rear window defogger relay power window relay, which is found in the car Isuzu Trooper II (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror defogger switch rear window defogger relay power window relay (1 of 1)
A/T
ALARM, RELAY CONTROL UNIT
B-48 B-49
B-52
B-6
B-7
BLK RED/ WIRE
BLK WIRE
BLK/ WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ WHT WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRAKE SWITCH
C-11 (AUDIO [ACC]) MIRROR FUSE
C-12 CIGAR FUSE
C-13 ANTI-THEFT FUSE
C-2 (SEAT HEATER) FUSE
C-4 ELEC. IGN. FUSE
C-5 FRT WIPER, WASHER FUSE
C-6 RR WIPER, WASHER FUSE C-7 (NOT USED)
CIGARETTE LIGHTER
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL SWITCH
DASH FUSE BOX (LEFT KICK PANEL)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
FROM FUSE FL-2 (DIAGRAM 1 OF 3)
GRN/RED WIRE
I-15
I-21
I-22
KEYLESS ENTRY, SECURITY CONTROL UNIT
LOCK
LOCK OFF
LOCK OFF ON
M/T
MIRROR CONTROL SWITCH RADIO
MIRROR DEFOGGER SWITCH REAR WINDOW DEFOGGER RELAY POWER WINDOW RELAY
MIRROR FOLDING SWITCH CLOCK ACCESSORY METER
OFF
ORG/ BLU WIRE
ORG/BLK WIRE
ORG/GRN WIRE
REAR DEFOGGER SWITCH CLUTCH SWITCH G-SENSOR ABS
REAR WIPER MOTOR REAR WIPER/WASHER SWITCH
RED WIRE
RIGHT FRONT SEAT HEATER SWITCH DRIVER'S SEAT HEATER SWITCH
SHIFT LOCK CONTROLLER
STARTER SWITCH
SWITCH
TO FUSE C-1 (DIAGRAM 3 OF 3)
TO FUSE C-8 (DIAGRAM 3 OF 3)
TOD CONTROL UNIT COMBINATION SWITCH
TRANSMISSION SWITCH 1-2 CONTROL UNIT
WHT GRN/ WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/ BLU WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WINDSHIELD WIPER MOTOR
YEL BLK/ WIRE
Go to component -> Power distribution circuit (2 of 3) -> MIRROR DEFOGGER SWITCH REAR WINDOW DEFOGGER RELAY POWER WINDOW RELAY
