Isuzu Trooper II (1992-2002) ignition door open input key in ign lights on input seat belt input Wiring diagram
This page shows the only wiring diagram for the component.ignition door open input key in ign lights on input seat belt input, which is found in the car Isuzu Trooper II (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition door open input key in ign lights on input seat belt input (1 of 1)
26 15 I-9
ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
B-12
B-6
BLK WIRE
BLU WIRE
BLU/WHT WIRE
C-10 METER GAUGE FUSE
C-16 CLOCK (B) DOME LIGHT FUSE
C-4 ELEC. IGN. FUSE
COMBINATION SWITCH
DASH FUSE BOX (BEHIND LEFT KICK PANEL)
F-12 TAIL FUSE
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPART- MENT)
GRN WIRE
GRN/RED WIRE
GROUND B-7
GRY WIRE
GRY/RED WIRE
HEAD OFF
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION DOOR OPEN INPUT KEY IN IGN LIGHTS ON INPUT SEAT BELT INPUT
KEY REMINDER SWITCH (CLOSED WITH KEY IN IGNITION)
LEFT FRONT DOOR SWITCH (IN LEFT FRONT B PILLAR)
LIGHTING SWITCH
LUXURY, PERFORMANCE MODELS
METER ASSEMBLY 2 5 I-9
PARK
PNK WIRE
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
S MODEL
SEAT BELT WARNING LIGHT
STARTER SWITCH
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL LIGHT RELAY
WHT WIRE
YEL WIRE
