Isuzu Trooper II (1992-2002) i-32 automatic heater a/c control unit solid state Wiring diagram
This page shows the only wiring diagram for the component.i-32 automatic heater a/c control unit solid state, which is found in the car Isuzu Trooper II (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i-32 automatic heater a/c control unit solid state (1 of 1)
24 7 I-9 METER ASSEMBLY
ACCESSORY METER
ANTI-THEFT SYSTEM
ASHTRAY ILLUMI- NATION
BLK WIRE
CIGARETTE LIGHTER ILLUMINATION
CLOCK
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH
F-12 TAIL FUSE
FOG LIGHT SWITCH
FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
GLOVE BOX ILLUMI- NATION
GRN WIRE
GRN/RED WIRE
HAZARD WARNING SWITCH
HEAD PARK
HOT AT ALL TIMES
I-15
I-32
I-32 AUTOMATIC HEATER A/C CONTROL UNIT SOLID STATE
I-9 8 25
ILLUMINATION
ILLUMINATION CONTROLLER
LEFT FRONT VANITY MIRROR LIGHT
LIGHTING SWITCH
M/T A/T
METER ASSEMBLY
MIRROR CONTROL SWITCH
MIRROR DEFOGGER SWITCH
MIRROR FOLDING SWITCH
OFF
POWER/ WINTER SWITCH (2 BULBS)
RADIO OR RADIO/ CD PLAYER SWITCH SOLID STATE
REAR DEFOGGER SWITCH
REAR WIPER/ WASHER SWITCH
RED WIRE
RED/BLK WIRE
RIGHT FRONT VANITY MIRROR LIGHT
S MODEL LUXURY,
SHIFT LEVER LIGHT
SOLID STATE
TAILLIGHT RELAY
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> I-32 AUTOMATIC HEATER A/C CONTROL UNIT SOLID STATE
