Isuzu Trooper II (1992-2002) hot in on or start c-6 rr wiper, washer fuse Wiring diagram
This page shows the only wiring diagram for the component.hot in on or start c-6 rr wiper, washer fuse, which is found in the car Isuzu Trooper II (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in on or start c-6 rr wiper, washer fuse (1 of 1)
2 3 4 8 9 18 RR MTR CTRL RR MTR CTRL IGNITION RR WPR SW IN GROUND RR WPR SW IN
ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
B-7
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
DASH FUSE BOX (BEHIND LEFT KICK PANEL)
GRN/RED WIRE
HOT IN ON OR START C-6 RR WIPER, WASHER FUSE
ILLUMINATION
INT OFF WASH
LT BLU WIRE
LT GRN WIRE
LT GRN/BLU WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
PARK
REAR WASHER MOTOR (LOWER CENTER OF LEFT TAILGATE DOOR)
REAR WIPER MOTOR (IN CENTER OF LEFT TAILGATE DOOR)
REAR WIPER/ WASHER SWITCH
RED/GRN WIRE
RUN WIRE
YEL WIRE
Go to component -> Rear wiper/washer circuit -> HOT IN ON OR START C-6 RR WIPER, WASHER FUSE
