Isuzu Trooper II (1992-2002) fl-1 main sw fuse wiring diagram
This page shows the only wiring diagram for the component.fl-1 main sw fuse, which is found in the car Isuzu Trooper II (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fl-1 main sw fuse wiring diagram (1 of 1)
28 22 1999-01 1998
AIR CONDITIONING SYSTEM
ALTERNATOR
ANTI-THEFT, KEYLESS ENTRY CONTROL UNIT (BEHIND FRONT CONSOLE)
AUTOMATIC TRANSMISSION MODE SWITCH (LEFT SIDE OF TRANSMISSION)
B-11
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
C-1 STARTER RELAY
DASH FUSE BOX (BEHIND LEFT KICK PANEL)
FL-1 MAIN SW FUSE
FL-2 KEY SW. FUSE
FUSE
FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
LOCK OFF ON
P-2
P-3
PULL- IN COIL HOLD- IN COIL
RED WIRE
STARTER MOTOR
STARTER MOTOR (LOWER LEFT REAR OF ENGINE) P-4
STARTER RELAY
STARTER SOLENOID
STARTER SWITCH
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Starting circuit, a/t -> FL-1 MAIN SW FUSE
