Isuzu Trooper II (1992-2002) aps 1 input reference tps 1 vss input valve motor + ignition ignition 38 78 27 Wiring diagram

APS 1 INPUT REFERENCE TPS 1 VSS INPUT VALVE MOTOR + IGNITION IGNITION 38 78 27 APS 3 INPUT APS 2 INPUT AUTOMATIC TRANSMISSION MODE SWITCH (LEFT SIDE OF TRANSMISSION) BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) BRN/YEL WIRE C-10 METER GAUGE FUSE C-14 STOPLIGHT A/T CONT FUSE C-3 BACK TURN FUSE C-4 ELEC. IGN. FUSE C-8 ENGINE FUSE CLUTCH SWITCH (ON CLUTCH PEDAL SUPPORT) COMBINATION SWITCH CRUISE CONTROL MAIN SWITCH CRUISE CONTROL SWITCH CRUISE MAIN INDICATOR LIGHT DASH FUSE BOX (BEHIND LEFT KICK PANEL) E-21 E-22 19 75 IGNITION IGNITION SENSOR GROUND ECM OR PCM (RIGHT SIDE OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT IN ON OR START I-9 CRUISE SET INDICATOR LIGHT ILLUMINATION LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE METER ASSEMBLY ORG/ WIRE ORG/BLK WIRE OTHER PNK/BLK WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RESUME/ ACCEL S MODEL SET/ COAST WHT WIRE YEL WIRE YEL/GRN WIRE
