Isuzu Trooper II (1992-2002) anti-lock brakes system pnk Wiring diagram
This page shows the only wiring diagram for the component.anti-lock brakes system pnk, which is found in the car Isuzu Trooper II (1992-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram anti-lock brakes system pnk (1 of 1)
15 I-9 18 I-9
ANTI-LOCK BRAKES SYSTEM PNK WIRE
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/RED WIRE
C-10 METER GAUGE FUSE C-4 ELEC IG FUSE
DASH FUSE BOX
FRONT AXLE SWITCH (UNDER SIDE OF VEHICLE, CENTER OF FRONT AXLE)
FRONT AXLE VACUUM SOLENOID VALVE (C)- GRAY
FRONT AXLE VACUUM SOLENOID VALVE (D)- BLUE
FRT AXLE VSV FRT AXLE VSV GND IGN
GRN WIRE
GRN/RED WIRE
HOT IN ON OR START
ILLUM
LT GRN WIRE
M-11
M-12
METER ASSEMBLY
OFF
ON/OFF IN FRT AXLE ENGAGED TRANS COMPLETE
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
SWITCH (ON TOP RIGHT OF TRANSFER CASE)
YEL WIRE
YEL/BLK WIRE
Go to component -> 4wd circuit, shift on the fly -> ANTI-LOCK BRAKES SYSTEM PNK WIRE
