Isuzu Rodeo II (1998-2004) Front wiper/washer circuit

11 10 9 22 I-42 WASH INPUT VAR INT INPUT REF GND 3 1 7 2 I-41 IGNITION OFF INPUT INT INPUT RUN/PARK IN ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL) B-6 (UNDER CENTER CONSOLE) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE C-16 (LEFT REAR CORNER OF ENGINE COMPT, ON INNER FENDER PANEL) C-36/P-6 (RIGHT SIDE OF ENGINE COMPT, BEHIND BATTERY) COMBINATION SWITCH DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) FRONT WIPER, WASHER FUSE 17 HOT IN ON OR START INT LO HI LO HI LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE OFF OFF INT PARK RED WIRE RUN WIRE VARIABLE INTERMITTENT W/ VARIABLE INTERMITTENT WIPERS WASH WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER MOTOR (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT, ON FIREWALL) WINDSHIELD WIPER/WASHER SWITCH YEL WIRE
