Charging circuit for Isuzu Rodeo II (1998-2004)

Charging circuit

Get access

BATTERY BLK WIRE BLK/RED WIRE CHARGING SYSTEM WARNING LIGHT DASH FUSE BOX FUSE CB-11 METER FUSE EB-16 MAIN FUSE EB-3 ACG-S FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) GENERATOR GRN/YEL WIRE HOT IN ON OR START I-1 JUNCTION CONNECTOR METER ASSEMBLY P-10 (LOWER RIGHT FRONT OF ENGINE) P-11 P-2 P-6/C-36 (RIGHT SIDE OF ENGINE COMPT, BEHIND BATTERY) P-8 P-9 RED WIRE STARTING SYSTEM (STARTER SOLENOID) WHT WIRE WHT/BLU WIRE YEL WIRE
