2.2l, starting circuit for Isuzu Rodeo II (1998-2004)

2.2l, starting circuit

Get access

A/T AUTOMATIC TRANSMISSION MODE SWITCH (ON LEFT SIDE OF TRANS) B-8 (UNDER CENTER CONSOLE) BATTERY BLK WIRE BLK/GRN WIRE BLK/WHT WIRE CLUTCH DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE CB-3 STARTER FUSE EB-16 MAIN FUSE EB-19 FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) JUNCTION CONNECTOR A KEYLESS ENTRY, ANTI-THEFT CONTROL UNIT (ABOVE RIGHT KICK PANEL) STR RLY CTRL LOCK OFF M/T P-10 (LOWER RIGHT FRONT OF ENGINE) P-2 P-3 P-4 STARTER SOLENOID P-6/C-36 (RIGHT SIDE OF ENGINE COMPT, BEHIND BATTERY) RED WIRE STARTER STARTER MOTOR STARTER RELAY STARTER SWITCH SWITCH (CLUTCH PEDAL SUPPORT) W/ ANTI- THEFT W/O ANTI- THEFT WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
