Shift interlock circuit for Isuzu Rodeo II (1998-2004)
Shift interlock circuit
BLK WIRE
BLU WIRE
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
HOT AT ALL TIMES CB-6 STOP LIGHT FUSE
HOT IN ON OR START CB-11 METER FUSE
ILLUM
PARKING POSITION DETECT SWITCH
RED WIRE
SHIFT LOCK CONTROLLER
SHIFT LOCK RELAY (BELOW SHIFT LEVER COVER)
SHIFT LOCK SOLENOID
WHT WIRE
WHT/GRN WIRE
YEL WIRE
