Power top/sunroof circuits for Isuzu Rodeo II (1998-2004)

Power top/sunroof circuits

Get access

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BRN WIRE CLOSE/ TILT (POP-UP) CLOSE/ TILT (POP-UP) RELAY DASH FUSE BOX ELEC. IG FUSE 15 GRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ON J-1 J-2 LIMIT SWITCHES OPEN RELAY ORG/ WIRE POP-UP SWITCH (1) POWER WINDOW C.B. 21 POWER WINDOW RELAY POWER WINDOW SYSTEM RED WIRE SAFETY STOP SWITCH (2) SOLID STATE SUN ROOF CONTROL UNIT (CENTER FRONT OF ROOF) SUN ROOF MOTOR (CENTER FRONT OF ROOF) SUN ROOF SWITCH VIO WIRE WHT WIRE YEL WIRE
