Power door lock circuit, without keyless entry for Isuzu Rodeo II (1998-2004)
Power door lock circuit, without keyless entry
B-8 (UNDER CENTER CONSOLE)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DOOR LOCK SWITCH
DRIVER'S DOOR KEY SWITCH
DRIVER'S DOOR LOCK ACTUATOR
DRIVER'S POWER WINDOW, DOOR LOCK SWITCH
FRONT PASS. DOOR LOCK ACTUATOR
FRONT PASSENGER'S POWER WINDOW, DOOR LOCK SWITCH
HOT AT ALL TIMES
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LT GRN WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
POWER DOOR LOCK FUSE 7
RED WIRE
RED/BLU WIRE
RIGHT REAR DOOR LOCK ACTUATOR
TAILGATE DOOR LOCK ACTUATOR
UNLOCK
WHT WIRE
YEL WIRE
