Instrument illumination circuit for Isuzu Rodeo II (1998-2004)
Instrument illumination circuit
2 11 (W/ AMPLIFIER)
3 10 (W/ AMPLIFIER)
ASHTRAY LIGHT
B-8 (UNDER CENTER CONSOLE)
BLK WIRE
CLOCK
COMBINATION SWTICH HEADLIGHT SWITCH
CRUISE CONTROL MAIN SWITCH
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
ENGINE CONTROLS, DOOR LOCKS SYSTEMS
FOG LIGHT SWITCH
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HEAD
HEATER-A/C CONTROL PANEL
HOT AT ALL TIMES
I-2
ILLUMINATION CONTROLLER
ILLUMINATION CONTROLLER LIGHT
INTELLIGENT SUSPENSION MODE
METER ASSEMBLY
OFF
PARK
POWER/ WINTER SWITCH
RADIO
REAR WINDOW DEFOGGER SWITCH
REAR WIPER SWITCH
RED WIRE
RED/BLK WIRE
SHIFT LOCK CONTROLLER
SOLID STATE
SWITCH
TAIL/ILLUM LIGHT FUSE 4
TAILLIGHT RELAY
WHT WIRE
YEL WIRE
