3.2l, cooling fan circuit for Isuzu Rodeo II (1998-2004)
3.2l, cooling fan circuit
A/C SWITCH
A/C TRIPLE PRESSURE SWITCH (LEFT SIDE OF RADIATOR GRILLE)
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BRN WIRE
C-16 (LEFT REAR CORNER OF ENGINE COMPT, ON INNER FENDER PANEL)
CONDENSER FAN (BEHIND RIGHT SIDE OF RADIATOR GRILLE)
CONDENSER FAN RELAY
FUSE 20 COND FAN
FUSE 7 A/C
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
GRN/BLK WIRE
HOT AT ALL TIMES
HOT IN ON
PNK/WHT WIRE
