2.2l, cooling fan circuit, a/t for Isuzu Rodeo II (1998-2004)
2.2l, cooling fan circuit, a/t
A/C PRESS SW REFERENCE
A/C PRESSURE SWITCH (BEHIND LEFT SIDE OF RADIATOR GRILLE)
BLK WIRE
BLU WIRE
C-1
C-36/P-6 (RIGHT SIDE OF ENGINE COMPT, BEHIND BATTERY)
CNDNSR FAN HI RLY CNDNSR FAN LO RLY C-2
CNDNSR FAN OUT C-3
CONDENSER FAN HI RELAY
CONDENSER FAN LO RELAY
CONDENSER FAN RELAY (A/T)
ELECT FAN FUSE
ENGINE CONTROLS SYSTEM
FUSE/ RELAY BOX
FUSE/ RELAY BOX (ON RIGHT SIDE OF ENGINE COMPT)
GRN WIRE
GROUND C-2
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT HAND COOLING FAN
OPTION BOX 1 (AT RIGHT REAR OF ENGINE COMPT)
POWERTRAIN CONTROL MODULE (BELOW CENTER OF DASH)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HAND COOLING FAN
WHT WIRE
