Isuzu Rodeo II (1998-2004) reference a/c pressure sw input a/c comp relay ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. reference a/c pressure sw input a/c comp relay ctrl, in which he is found in the car Isuzu Rodeo II (1998-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram reference a/c pressure sw input a/c comp relay ctrl (1 of 2)
A/C COMPRESSOR
A/C COMPRESSOR RELAY
A/C PRESSURE SWITCH (BEHIND LEFT SIDE OF RADIATOR GRILLE)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
C-1
C-2
C-3
CB-15 ELEC. IG FUSE
CLUTCH
CONDENSER FAN HI RELAY
CONDENSER FAN HI RELAY (A/T)
CONDENSER FAN HI RELAY CTRL CONDENSER FAN LO RELAY CTRL GROUND
CONDENSER FAN LO RELAY
CONDENSER FAN OUTPUT A/C ON INPUT
DASH FUSE BOX (LEFT SIDE OF DASH, BEHIND PANEL)
EB-16 MAIN FUSE
EB-20 ELEC FAN FUSE
EB-5 BLOWER FUSE
EB-6 BLOWER FUSE EB-7 A/C FUSE
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT, ON INNER FENDER PANEL)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/RED WIRE
HEATER-A/C RELAY
HOT AT ALL TIMES
HOT IN ON
J/C A
LEFT HAND COOLING FAN
OPTION BOX 1 (RIGHT SIDE OF ENGINE COMPARTMENT, ON INNER FENDER PANEL)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
REFERENCE A/C PRESSURE SW INPUT A/C COMP RELAY CTRL
RIGHT HAND COOLING FAN
THERMO SWITCH RELAY
WHT WIRE
Go to component -> 2.2l, manual a/c circuit, a/t (2 of 2) -> REFERENCE A/C PRESSURE SW INPUT A/C COMP RELAY CTRL
Wiring diagram reference a/c pressure sw input a/c comp relay ctrl (2 of 2)
A/C COMPRESSOR
A/C COMPRESSOR RELAY
A/C PRESSURE SWITCH (BEHIND LEFT SIDE OF RADIATOR GRILLE)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
C-1
C-2
C-3
CB-15 ELEC. IG FUSE
CLUTCH
CONDENSER FAN
CONDENSER FAN HI RELAY
CONDENSER FAN HI RELAY CTRL CONDENSER FAN LO RELAY CTRL GROUND
CONDENSER FAN LO RELAY
CONDENSER FAN OUTPUT A/C ON INPUT
DASH FUSE BOX (LEFT SIDE OF DASH, BEHIND PANEL)
EB-16 MAIN FUSE
EB-20 ELEC FAN FUSE
EB-5 BLOWER FUSE
EB-6 BLOWER FUSE EB-7 A/C FUSE
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT, ON INNER FENDER PANEL)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/RED WIRE
HEATER-A/C RELAY
HOT AT ALL TIMES
HOT IN ON
J/C A
LT GRN WIRE
OPTION BOX 1 (RIGHT SIDE OF ENGINE COMPARTMENT, ON INNER FENDER PANEL)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
REFERENCE A/C PRESSURE SW INPUT A/C COMP RELAY CTRL
THERMO SWITCH RELAY
WHT WIRE
YEL WIRE
Go to component -> 2.2l, manual a/c circuit, m/t (2 of 2) -> REFERENCE A/C PRESSURE SW INPUT A/C COMP RELAY CTRL
