Isuzu Rodeo II (1998-2004) driver's inflator module Wiring diagrams
This page contains all the electrical diagrams for the component. driver's inflator module, in which he is found in the car Isuzu Rodeo II (1998-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver's inflator module wiring diagram (1 of 2)
ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
BLK WIRE
DRIVER'S INFLATOR MODULE
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HIGH NOTE HORN (BEHIND RIGHT SIDE OF RADIATOR GRILLE)
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES FUSE 2 HORN
LOW NOTE HORN (BEHIND RIGHT SIDE OF RADIATOR GRILLE)
LSE
ORG/BLK WIRE
SRS COIL ASSEMBLY
STEERING WHEEL)
Go to component -> Horn circuit -> DRIVER'S INFLATOR MODULE
driver's inflator module wiring diagram (2 of 2)
1 2 3 DLC OUTPUT
2.2L
AIR BAG READINESS INDICATOR LIGHT
BLK WIRE
BLK/RED WIRE
BRN WIRE
CB-11 METER FUSE
CB-22 SRS FUSE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DRIVER'S INFLATOR MODULE
DRIVER'S SEAT BELT BUCKLED INPUT
ENGINE CONTROLS SYSTEM
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT IN ON OR START
I-1
IGNITION
INDICATOR 8 9 10 11 12 13 14 15
LOW 17 18 19 20 21 22 23 24
LOW 5 6
METER ASSEMBLY
PASSENGER'S INFLATOR MODULE
RED WIRE
SENSING, DIAGNOSTIC MODULE (SDM) (BELOW CENTER OF DASH)
SERIAL DATA
SRS COIL ASSEMBLY
STEERING WHEEL)
WARNING SYSTEMS
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit -> DRIVER'S INFLATOR MODULE
