Courtesy lamps circuit for Isuzu Rodeo I (1989-1998)
Courtesy lamps circuit
1995 1996, 1997
ANTI-THEFT CONNECTOR
BLK WIRE
BLK/WHT WIRE
DASH FUSE BOX (LEFT SIDE OF DASH)
DASH FUSE BOX (LEFT SIDE OF I/P)
DIODE BOX F
DIODE BOX G
DOME LIGHT
DOOR
HATCH GATE OPEN SWITCH (INSIDE TOP CENTER OF TAILGATE)
HOT AT ALL TIMES
LEFT FRONT COURTESY LIGHT
LEFT FRONT DOOR SWITCH (REAR OF LEFT FRONT DOOR AREA)
LEFT MAP LIGHT
LEFT REAR COURTESY LIGHT
LEFT REAR DOOR SWITCH (REAR OF LEFT REAR DOOR AREA)
LEFT SPOT LIGHT SWITCH
LT GRN WIRE
LUGGAGE ROOM LIGHT
OFF
OPTIONAL
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT COURTESY LIGHT
RIGHT FRONT DOOR SWITCH (REAR OF RIGHT FRONT DOOR AREA)
RIGHT MAP LIGHT
RIGHT REAR COURTESY LIGHT
RIGHT REAR DOOR SWITCH (REAR OF RIGHT REAR DOOR AREA)
RIGHT SPOT LIGHT SWITCH
ROOM FUSE
SPOT LIGHT ASSEMBLY
WARNING SYSTEM
WIPER/ WASHER SYSTEM
