Car Wiring Diagrams for Heater circuit for Isuzu Rodeo I (1989-1998)

1995 VFTC BLK WIRE BLOWER FUSE BLOWER MOTOR (BEHIND RIGHT SIDE OF I/P) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) GENERATOR (RIGHT FRONT CORNER OF ENGINE COMPARTMENT) HEATER CONTROL PANEL BLOWER SWITCH HEATER RELAY HOT AT ALL TIMES INDICATOR CONTROL LT GRN WIRE MAIN FUSE 1 OFF ORG/ WIRE RED WIRE RESISTOR BLOCK (BEHIND RIGHT SIDE OF I/P) THERMO FUSE VOLTAGE REGULATOR WHT WIRE WHT/BLU WIRE WHT/RED WIRE
