3.2l, a/c circuit for Isuzu Rodeo I (1989-1998)

3.2l, a/c circuit (1 of 2)

Get access

A/C COMPRESSOR CLUTCH A/C COMPRESSOR RELAY A/C COMPRESSOR RELAY CNTL A/C ON INPUT A/C SWITCH A/C THERMO SWITCH (LEFT FRONT CORNER OF ENGINE COMPARTMENT) BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/YEL WIRE COND FAN FUSE CONDENSER FAN (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) CONDENSER FAN RELAY DASH FUSE BOX ENGINE CONTROL MODULE (ECM) (BEHIND LEFT SIDE KICK PANEL) ENGINE DEVICE FUSE FUSE/ RELAY BOX FUSE/RELAY BOX GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START LT GRN/BLK WIRE NOISE CONDENSER (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) PNK/WHT WIRE THERMO SWITCH RELAY WHT WIRE WHT/GRN WIRE

Get access

A/C DUAL PRESSURE SWITCH (LEFT FRONT SIDE OF ENGINE COMPARTMENT) A/C TRIPLE PRESSURE SWITCH (LEFT FRONT SIDE OF ENGINE COMPARTMENT) A/T AIR CON FUSE ALTERNATOR (RIGHT FRONT CORNER OF ENGINE COMPARTMENT) BLK WIRE BLOWER FUSE BLOWER MOTOR (BEHIND RIGHT SIDE OF I/P) BLOWER SWITCH BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE ELECTRONIC THERMOSTAT (BEHIND RIGHT SIDE OF I/P) EVAPORATOR TEMPERATURE SENSOR FAN CONTROL SWITCH BLOWER SWITCH FUSE/RELAY BOX GRN/RED WIRE GRN/WHT WIRE HEATER-A/C RELAY HI LO HOT AT ALL TIMES INDICATOR CONTROL LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE M/T MAIN FUSE OFF ORG/ WIRE PNK/WHT WIRE RED WIRE RESISTOR BLOCK (BEHIND RIGHT SIDE OF I/P) THERMO FUSE SOLID STATE VOLTAGE REGULATOR WHT WIRE WHT/BLU WIRE WHT/RED WIRE
