Isuzu Rodeo I (1989-1998) indicator control Wiring diagrams
This page contains all the electrical diagrams for the component. indicator control, in which he is found in the car Isuzu Rodeo I (1989-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
indicator control wiring diagram (1 of 4)
1995 VFTC
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR RELAY
A/C DUAL PRESSURE SWITCH
A/C SWITCH
AIR CON FUSE
ALTERNATOR
BLK WIRE
BLOWER FUSE
BLOWER MOTOR
BLOWER SWITCH
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
DASH FUSE BOX
ELECTRONIC THERMOSTAT
ENGINE CONTROL MODULE (BEHIND LEFT KICK PANEL)
ENGINE DEVICE FUSE
EVAPORATOR TEMPERATURE SENSOR
FAN CONTROL SWITCH BLOWER SWITCH
FUSE/RELAY BOX
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HEATER-A/C RELAY
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR CONTROL
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE
NCA WIRE
OFF
ORG/ WIRE
RED WIRE
RESISTOR BLOCK THERMO FUSE (BEHIND GLOVE BOX)
SOLID STATE
THERMO SWITCH RELAY
VOLTAGE REGULATOR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> 2.6l, a/c circuit -> INDICATOR CONTROL
indicator control wiring diagram (2 of 4)
A/C DUAL PRESSURE SWITCH (LEFT FRONT SIDE OF ENGINE COMPARTMENT)
A/C TRIPLE PRESSURE SWITCH (LEFT FRONT SIDE OF ENGINE COMPARTMENT)
A/T
AIR CON FUSE
ALTERNATOR (RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLOWER FUSE
BLOWER MOTOR (BEHIND RIGHT SIDE OF I/P)
BLOWER SWITCH
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
ELECTRONIC THERMOSTAT (BEHIND RIGHT SIDE OF I/P)
EVAPORATOR TEMPERATURE SENSOR
FAN CONTROL SWITCH BLOWER SWITCH
FUSE/RELAY BOX
GRN/RED WIRE
GRN/WHT WIRE
HEATER-A/C RELAY
HI LO
HOT AT ALL TIMES
INDICATOR CONTROL
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/YEL WIRE
M/T
MAIN FUSE
OFF
ORG/ WIRE
PNK/WHT WIRE
RED WIRE
RESISTOR BLOCK (BEHIND RIGHT SIDE OF I/P) THERMO FUSE
SOLID STATE
VOLTAGE REGULATOR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> 3.2l, a/c circuit (2 of 2) -> INDICATOR CONTROL
indicator control wiring diagram (3 of 4)
1995 VFTC
BLK WIRE
BLOWER FUSE
BLOWER MOTOR (BEHIND RIGHT SIDE OF I/P)
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
GENERATOR (RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
HEATER CONTROL PANEL BLOWER SWITCH
HEATER RELAY
HOT AT ALL TIMES
INDICATOR CONTROL
LT GRN WIRE
MAIN FUSE 1
OFF
ORG/ WIRE
RED WIRE
RESISTOR BLOCK (BEHIND RIGHT SIDE OF I/P) THERMO FUSE
VOLTAGE REGULATOR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Heater circuit -> INDICATOR CONTROL
indicator control wiring diagram (4 of 4)
1995 VFTC
BLK WIRE
BLOWER FUSE
BLOWER MOTOR (BEHIND RIGHT SIDE OF I/P)
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
GENERATOR (RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
HEATER CONTROL PANEL BLOWER SWITCH
HEATER RELAY
HOT AT ALL TIMES
INDICATOR CONTROL
LT GRN WIRE
MAIN FUSE 1
OFF
ORG/ WIRE
RED WIRE
RESISTOR BLOCK (BEHIND RIGHT SIDE OF I/P) THERMO FUSE
VOLTAGE REGULATOR
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Heater circuit -> INDICATOR CONTROL
