Isuzu Rodeo I (1989-1998) diode box a Wiring diagrams
This page contains all the electrical diagrams for the component. diode box a, in which he is found in the car Isuzu Rodeo I (1989-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram diode box a (1 of 2)
AUTOMATIC TRANSMISSION MODE SWITCH (ON LEFT SIDE OF TRANSMISSION)
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BRN WIRE
DASH FUSE BOX
DIODE BOX A
FUSE/ RELAY BOX
FUSE/ RELAY BOX STARTER RELAY
HATCH GLASS RELEASE SYSTEM
IGNITION SWITCH
LOCK OFF ON
MAIN FUSE 16
PNK WIRE
RED WIRE
STARTER
STARTER FUSE 1
STARTER MOTOR
STARTER SHORT CONNECTOR (LEFT KICK PANEL)
STARTER SOLENOID
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> 3.2l, starting circuit, a/t -> DIODE BOX A
Wiring diagram diode box a (2 of 2)
1995 ONLY
A/T
AUTOMATIC TRANSMISSION MODE SWITCH (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU/BLK WIRE
BRN/RED WIRE
CB-17 RR DEF 1 FUSE
CB-18 RR DEF 2 FUSE
DASH FUSE BOX (LEFT SIDE OF DASH)
DIODE BOX A
FUSE/ RELAY BOX
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HATCH GATE GLASS OPENER ACTUATOR (CENTER OF TAILGATE)
HATCH GATE GLASS OPENER SWITCH
HATCH GATE OPEN SWITCH (CENTER OF TAILGATE)
HATCH OPEN IND
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHTS
LT GRN WIRE
M/T
OFF WIPE
PARK
PARKING BRAKE SWITCH (UNDER CENTER CONSOLE)
PNK/BLK WIRE
PNK/BLU WIRE
PPL
REAR WASHER SWITCH WASH OFF
REAR WIPER MOTOR ON SWITCH (RIGHT SIDE OF TAILGATE)
REAR WIPER SWITCH
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RUN WIRE
STARTER RELAY
STARTING/ CHARGING SYSTEM
YEL WIRE
Go to component -> Rear glass release circuit -> DIODE BOX A
