Isuzu Oasis I (1995-1999) map lights ex Wiring diagrams
This page contains all the electrical diagrams for the component. map lights ex, in which he is found in the car Isuzu Oasis I (1995-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram map lights ex (1 of 2)
ANTI-THEFT SYSTEM (OPTIONAL)
BLK WIRE
BLK/BLU WIRE
CARGO AREA LIGHTS
DOOR
DOOR LOCKS SYSTEM
DOOR OPEN INPUT
DOOR OPEN OUTPUT
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR SWITCH
EX LX
FRONT CEILING LIGHT
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S DOOR SWITCH
GAUGE ASSEMBLY
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IN-LINE DIODE (BEHIND LEFT I/P)
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHT FUSE 37
J/C
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR SWITCH
LX, EX
MAP LIGHTS EX
OFF
ON OFF
ORG/ WIRE
ORG/GRN WIRE
ORN/
REAR CEILING LIGHT
RIGHT REAR DOOR COURTESY LIGHT
RIGHT REAR DOOR SWITCH
SAFETY INDICATOR
TAILGATE LATCH SWITCH (LATCH ASSEMBLY)
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WHT/BLK WIRE
WHT/BLU WIRE
Go to component -> Courtesy lamps circuit -> MAP LIGHTS EX
Wiring diagram map lights ex (2 of 2)
1 3 (EX)
A/C COMPRESSOR CLUTCH RELAY
BACK-UP RADIO FUSE 39
BLK WIRE
CARGO AREA LIGHTS LEFT REAR DOOR COURTESY LIGHT
CIGARETTE LIGHTER
CIGARETTE LIGHTER RELAY (BEHIND FRONT CONSOLE)
COMBINATION LIGHT SWITCH
CONDENSER FAN FUSE 34
CONDENSER FAN RELAY
DATA LINK CONNECTOR (DLC)
DOOR LOCK FUSE 38
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S POWER SEAT UP/DOWN SWITCH (EX)
ECU FUSE 33
ENGINE CONTROL MODULE (ECM) (1995)
EX LX
FROM FUSE 11
FROM FUSE 22 (DIAGRAM 1 OF 4)
FROM FUSE 36 (DIAGRAM 2 OF 4) INTERIOR LIGHT FUSE 37
FRONT CEILING LIGHT REAR CEILING LIGHT
FRONT PASSENGER'S DOOR COURTESY LIGHT
GRN WIRE
HEADLIGHT RELAY
INTEGRATED CONTROL UNIT
KEYLESS DOOR LOCK CONTROL UNIT POWER DOOR LOCK CONTROL UNIT
MAP LIGHTS EX
MOONROOF OPEN RELAY MOONROOF CLOSE RELAY
PGM-FI MAIN RELAY
POWER SEAT HEIGHT FUSE 31
POWER WINDOW RELAY
POWERTRAIN CONTROL MODULE (PCM) (1996-97)
RADIATOR FAN CONTROL MODULE
RADIO CIGAR LIGHTER FUSE 36
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT REAR DOOR COURTESY LIGHT
SECURITY SYSTEM CONNECTOR (CANADA)
SMALL LIGHT FUSE 32
STEERING LOCK ASSEMBLY
STEREO RADIO/ CASSETTE PLAYER
STEREO RADIO/ CASSETTE PLAYER CLOCK
SUN ROOF FUSE 29
TO FUSE 37
TRANSMISSION CONTROL MODULE (TCM) (1995)
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 4) -> MAP LIGHTS EX
