Isuzu Oasis I (1995-1999) headlights on input Wiring diagram
This page shows the only wiring diagram for the component.headlights on input, which is found in the car Isuzu Oasis I (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlights on input (1 of 1)
BATTERY FUSE 15
BATTERY INPUT
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRAKE INDICATOR CONTROL
COMBINATION LIGHT SWITCH
DAY LIGHTS FUSE 10
DAYTIME RUNNING LIGHTS CONTROL UNIT (LEFT SIDE OF I/P)
DAYTIME RUNNING LIGHTS INDICATOR
DIMMER RELAY
DIMMER RELAY INPUT
DIMMER SWITCH
DRL OUTPUT
FLASH TO PASS SWITCH
FOG LIGHT IN LINE FUSE (RIGHT FRONT OF ENGINE COMPARTMENT)
FOG LIGHT RELAY (RIGHT FRONT OF ENGINE COMPARTMENT)
FOG LIGHT SWITCH
FUSIBLE LINK
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GROUND
HEAD
HEADLIGHT RELAY
HEADLIGHT SWITCH
HEADLIGHTS ON INPUT
HI BEAM CONTROL/ DRL MODE OUTPUT
HI BEAM/ DRL MODE CONTROL
HIGH BEAM INDICATOR LIGHT
HOT AT ALL TIMES
HOT IN ON
IGNITION INPUT
INDICATOR LIGHT CONTROL
INSTRUMENT CLUSTER SYSTEM
LEFT FOG LIGHT RIGHT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LEFT HEADLIGHT FUSE 19
LO HI
LOW BEAM CUT RELAY (ABOVE LEFT KICK PANEL)
OFF PARK
ORG/ WIRE
ORG/BLK WIRE
ORG/WHT WIRE
PARKING BRAKE INPUT
PARKING BRAKE SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY BOX (LEFT KICK PANEL)
RIGHT HEADLIGHT ASSEMBLY
RIGHT HEADLIGHT FUSE 20
RUNNING LIGHT FUSE 27
UNDER-DASH FUSE/
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Headlight circuit, with drl -> HEADLIGHTS ON INPUT
