Isuzu Oasis I (1995-1999) bi-lev switch Wiring diagram
This page shows the only wiring diagram for the component.bi-lev switch, which is found in the car Isuzu Oasis I (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bi-lev switch (1 of 1)
1995 VFTC
A/C ON INDI- CATOR
A/C SWITCH
BI-LEV SWITCH
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
DEFROST SWITCH
DIMMING CIRCUIT
FRESH
FUSE 4
FUSE 8
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HEAT SWITCH
HEAT/DEF SWITCH
HEATER CONTROL PANEL
HOT IN ON
HOT IN ON OR START
J/C
LT GRN/BLK WIRE
LT GRN/WHT WIRE
MED LO HI
MED LO HI OFF OFF
MODE CONTROL MOTOR (BELOW I/P, RIGHT OF STEERING COLUMN)
OFF
OFF HEATER FAN SWITCH
POWERTRAIN CONTROL MODULE (FRONT PASSENGER'S FOOTREST)
REAR A/C UNIT SWITCH
REAR BLOWER MOTOR IN-LINE FUSE
RECIRC
RECIRC FRESH/ RECIRC SWITCH FRESH
RECIRCULATION CONTROL MOTOR (BEHIND GLOVE BOX)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SUCTION LINE SOLENOID VALVE (CENTER REAR OF ENGINE COMPARTMENT)
UNDER-DASH FUSE/RELAY BOX
VENT SWITCH
WHT WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Air conditioning circuits (1 of 2) -> BI-LEV SWITCH
