Exterior lamps circuit for Isuzu Axiom I (2001-2004)
Exterior lamps circuit (1 of 2)
1 2 3 IGNITION OUTPUT GND
8 I-23
BLK WIRE
BRN WIRE
BRN/WHT WIRE
COMBINATION SWITCH
DASH FUSE BOX (ON LEFT OF DASH, BEHIND TRIM PANEL)
FLASHER UNIT (BEHIND LEFT KICK PANEL)
FUSE 1 HAZARD
FUSE 14 BACKUP/ TURN
FUSE/ RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HAZARD
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HOT AT ALL TIMES
HOT IN ON
I-23
LEFT
LEFT FRONT COMBINATION LIGHT
LEFT TURN INDICATOR LIGHT
OFF
OFF HAZARD
PNK 12 I-23 WIRE
PNK WIRE
RED WIRE
RIGHT
RIGHT FRONT COMBINATION LIGHT
RIGHT TURN INDICATOR LIGHT
TRAILER LIGHTING CONNECTOR (IN LEFT REAR CARGO COMPARTMENT, TAPED TO HARNESS)
TURN SIGNAL SWITCH
WHT WIRE
Exterior lamps circuit (2 of 2)
4 5 PNK WIRE
BLK WIRE
BRAKE SWITCH (BEHIND DASH, ON BRAKE PEDAL SUPPORT)
COMBINATION SWITCH
DASH FUSE BOX (ON LEFT OF DASH, BEHIND TRIM PANEL)
ENGINE CONTROLS SYSTEM
FUSE 4 TAIL
FUSE 6 STOP LAMP
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HEAD
HEADLIGHT SWITCH
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
KEYLESS ENTRY, SECURITY CONTROL UNIT (BEHIND GLOVE BOX)
LEFT LICENSE LIGHT
LEFT TAILLIGHT ASSEMBLY TAIL STOP
OFF PARK
PNK WIRE
RED WIRE
RIGHT LICENSE LIGHT
RIGHT TAILLIGHT ASSEMBLY
SHIFT INTERLOCK SYSTEMS
TAIL STOP
TAIL/STOP LIGHT
TAILLIGHT RELAY
TRANSMISSION, ANTI-LOCK BRAKES CRUISE CONTROL SYSTEMS
TURN LIGHT
WHT WIRE
YEL WIRE
