Isuzu Axiom I (2001-2004) hot at all times fuse 2 horn Wiring diagram
This page shows the only wiring diagram for the component.hot at all times fuse 2 horn, which is found in the car Isuzu Axiom I (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times fuse 2 horn (1 of 1)
ALARM, RELAY CONTROL UNIT (RIGHT SIDE OF DASH)
BLK WIRE
DRIVER'S INFLATOR MODULE
FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/ORG WIRE
GRN/YEL WIRE
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES FUSE 2 HORN
I-41
LEFT HORN (BEHIND LEFT SIDE OF RADIATOR GRILLE)
ORG/BLK WIRE
RIGHT HORN (BEHIND RIGHT SIDE OF RADIATOR GRILLE)
SRS COIL ASSEMBLY
STEERING WHEEL)
Go to component -> Horn circuit -> HOT AT ALL TIMES FUSE 2 HORN
