Isuzu Axiom I (2001-2004) check tod ind rear ind auto ind Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 C-38 1 9 A-1 2 10 A-1 4 H/L TRANSFER SWITCH ASSEMBLY 6 PNK WIRE 7 PNK WIRE 8 7 DATALINK CONNECTOR (LOWER LEFT SIDE OF DASH) 8 PNK WIRE A/T CIRCUIT ABS OUT AUTO IND TOD IND AUTOMATIC TRANSMISSION MODE SWITCH (LEFT SIDE OF TRANSMISSION) BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRAKE SW MTR POS 4 MTR POS 2 LAMPS ON ATM B IN AXLE ENGAGE BRAKE SWITCH (ON TOP OF BRAKE PEDAL SUPPORT) BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE C-26 C-26 (LEFT SIDE OF ENGINE COMPT) C-26 (LEFT SIDE OF ENGINE COMPT) H-L SHIFT MOTOR ASSEMBLY CHECK TOD IND REAR IND AUTO IND CLUTCH SOL +V REF SENS GRND IGNITION TPS IN DATA E-34 ENCODER SWITCHES ENG SPEED GROUND GROUND TOD IN FRONT AXLE MOTOR ACTUATOR (LEFT SIDE OF AXLE) FRONT IND REAR IND FSS SIG ABS ACTIVE BATTERY MOTOR H-L FUSE 11 METER FUSE 14 BACK UP/ TURN FUSE 14 TOD FUSE 6 STOP LAMP FUSE/ RELAY BOX (RIGHT SIDE OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GROUND MOTOR L-H GRY WIRE GRY/BLU WIRE GRY/RED WIRE H-L SHIFT MOTOR HOT AT ALL TIMES HOT IN ON OR START I-24 ILLUM INSTRUMENT CLUSTER SYSTEM INTERIOR LIGHTS LT BLU WIRE LT GRN/RED WIRE LT GRN/WHT WIRE METER ASSEMBLY ORG/BLK WIRE ORG/WHT WIRE P-15 (TOP OF TRANSFER CASE) PNK WIRE PNK/BLU WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) FRONT IND RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RPM OUT RSS SIG SHIFT-ON- THE-FLY CONTROLLER (BEHIND RADIO) TOD TORQUE ON DEMAND (TOD) SWITCH TORQUE-ON- DEMAND (TOD) CONTROL UNIT (BELOW LEFT SIDE OF DASH) TPS OUT TRANSFER CLUTCH SOLENOID (IN THE TRANSFER CASE) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/VIO WIRE YEL/WHT WIRE
