Isuzu Axiom I (2001-2004) battery input lock/unlock anti-theft horn ctrl dr door act ctrl Wiring diagram

7 21 16 I-41 ALARM, RELAY CONTROL UNIT (ON RIGHT SIDE OF DASH) ANTI-THEFT FUSE 20 ANTI-THEFT HORN (ON RIGHT SIDE OF ENGINE COMPARTMENT) ANTI-THEFT IND IGNITION INPUT GROUND AUDIO FUSE 2 B-9 (UNDER CENTER CONSOLE) BATTERY INPUT LOCK/UNLOCK ANTI-THEFT HORN CTRL DR DOOR ACT CTRL BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE DASH FUSE BOX (ON LEFT OF DASH, BEHIND TRIM PANEL) DIODE BOX 5 DIODE BOX 6 DOOR LOCK FUSE 7 DOOR LOCKS SYSTEM DOOR SWITCH DIODE DOOR/HATCH OPEN IN TAILLIGHT RELAY KEY IN IGNITION ENGINE HOOD SWITCH (AT RIGHT REAR CORNER OF ENGINE COMPARTMENT) FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT) GPS RECEIVER UNIT GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHTS SYSTEMS HORN FUSE 2 HOT AT ALL TIMES HOT IN ACC OR ON J/C B KEY REMINDER SWITCH (PART OF IGNITION SWITCH) KEYLESS ENTRY, ANTI-THEFT CONTROL UNIT (BEHIND GLOVE BOX) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LOCK OUTPUT DOOR LOCK POSIT IN LT GRN WIRE LT GRN/RED WIRE LT GRN/WHT WIRE P-10/C-10 (RIGHT SIDE OF ENGINE COMPT) PNK/BLU WIRE RED WIRE RED/BLU WIRE RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH STARTER RLY CTRL HEADLIGHT RLY CTRL TAILGATE OPEN SWITCH (ON BOTTOM OF TAILGATE) WARNING SYSTEMS WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIPER/ WASHER SYSTEMS YEL WIRE YEL/RED WIRE
