Power top/sunroof circuits for Isuzu Amigo II (1998-2000)
Power top/sunroof circuits
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CLOSE/ TILT (POP-UP)
CLOSE/ TILT (POP-UP) RELAY
DASH FUSE BOX
ELEC. IG FUSE 15
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON
J-1
J-2
LIMIT SWITCHES
OPEN RELAY
ORG/ WIRE
POP-UP SWITCH (1)
POWER WINDOW C.B. 21
POWER WINDOW RELAY
POWER WINDOW SYSTEM
RED WIRE
SAFETY STOP SWITCH (2)
SOLID STATE
SUN ROOF CONTROL UNIT (CENTER FRONT OF ROOF)
SUN ROOF MOTOR (CENTER FRONT OF ROOF)
SUN ROOF SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
