Isuzu Amigo II (1998-2000) low 17 18 19 20 21 22 23 24 Wiring diagram
This page shows the only wiring diagram for the component.low 17 18 19 20 21 22 23 24, which is found in the car Isuzu Amigo II (1998-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low 17 18 19 20 21 22 23 24 (1 of 1)
1 2 3 DLC OUTPUT
3.2L
AIR BAG READINESS INDICATOR LIGHT
BLK WIRE
BLK/RED WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DRIVER'S INFLATOR MODULE
DRIVER'S SEAT BELT BUCKLED INPUT
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT IN ON OR START
I-1
IGNITION
INDICATOR 8 9 10 11 12 13 14 15
LOW 17 18 19 20 21 22 23 24
LOW 5 6
METER ASSEMBLY
METER FUSE
PASSENGER'S INFLATOR MODULE
RED WIRE
SENSING, DIAGNOSTIC MODULE (SDM) (BELOW CENTER OF DASH)
SERIAL DATA
SRS COIL ASSEMBLY
SRS FUSE
STEERING WHEEL)
WARNING SYSTEMS
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit -> LOW 17 18 19 20 21 22 23 24
