Isuzu Amigo II (1998-2000) illum- ination controller Wiring diagrams
This page contains all the electrical diagrams for the component. illum- ination controller, in which he is found in the car Isuzu Amigo II (1998-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram illum- ination controller (1 of 2)
8 4 **
ALARM, RELAY CONTROL UNIT
AUTO LIGHT SENSOR (NOT
BACK UP PARK/ STOP TURN
BACK-UP TURN
BLK WIRE
BLU WIRE
CIGARETTE LIGHTER
COIL
COIL COIL
COMBINATION SWITCH
CRUISE CONTROL UNIT CONTROL UNIT
DASH FUSE BOX ACCESSORY SOCKET POWER RELAY POWER WINDOW RELAY
DRIVER'S DOOR KEY DETECT SWITCH
DRIVER'S DOOR KEY DETECT, ACTUATOR POSITION SWITCHES
DRIVER'S POWER WINDOW, DOOR LOCK SWITCH
DRIVER'S SEAT BELT SWITCH
EX LX
FAN CONTROL SWITCH
FLASHER UNIT
FRONT ACCESSORY POWER SOCKET
FRONT PASS- ENGER'S DOOR ACTUATOR POSITION SWITCH
FRONT PASS- ENGER'S DOOR KEY DETECT SWITCH
FRONT PASS- ENGER'S POWER WINDOW, DOOR LOCK SWITCH
FUEL TANK UNIT
GAUGE ASSEMBLY CLOCK
GRN WIRE
HIGH MOUNTED STOP LIGHT
ILLUM- INATION CONTROLLER
KEYLESS ENTRY, SECURITY CONTROL UNIT SHIFT LOCK SOLENOID
LEFT FRONT VANITY MIRROR LIGHT
LEFT MAP LIGHT RIGHT MAP LIGHT
LEFT POWER MIRROR
LEFT REAR DOOR ACTUATOR POSITION SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT TAILLIGHT ASSEMBLY
LICENSE PLATE LIGHT
MIRROR CONTROL SWITCH
MOON ROOF CONTROL UNIT REAR ACCESSORY POWER SOCKET
PARK STOP
PARKING POSITION DETECT SWITCH
PASSPORT, RODEO
RADIO
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER SWITCH
RIGHT FRONT VANITY MIRROR LIGHT REAR VIEW MIRROR
RIGHT LICENSE LIGHT LEFT LICENSE LIGHT
RIGHT POWER MIRROR
RIGHT REAR DOOR ACTUATOR POSITION SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT TAILLIGHT ASSEMBLY
SHIFT LOCK CONTROLLER
STARTER RELAY
SUNROOF CONTROL UNIT
TRAILER LIGHTING CONNECTOR POWER/WINTER SWITCH
USED)
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> ILLUM- INATION CONTROLLER
Wiring diagram illum- ination controller (2 of 2)
