Isuzu Amigo II (1998-2000) i-41 i-42 i-41 i-42 2 15 9 22 wash input gnd Wiring diagram
This page shows the only wiring diagram for the component.i-41 i-42 i-41 i-42 2 15 9 22 wash input gnd, which is found in the car Isuzu Amigo II (1998-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i-41 i-42 i-41 i-42 2 15 9 22 wash input gnd (1 of 1)
ALARM, RELAY CONTROL UNIT (ABOVE RIGHT KICK PANEL)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION SWITCH
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
HOT IN ON OR START FRONT WIPER, WASHER FUSE
I-41 I-42 I-41 I-42 2 15 9 22 WASH INPUT GND
I-42 I-42 I-42 I-42
INT LO HI OFF
LO HI
LT GRN WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
M/T A/T
MIST
OFF
OFF INT
PARK
RED WIRE
RUN WIRE
WASH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT, ON FIREWALL)
WINDSHIELD WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit, without intermittent -> I-41 I-42 I-41 I-42 2 15 9 22 WASH INPUT GND
