Isuzu Amigo II (1998-2000) fuse 2 fuse 19 audio Wiring diagram
This page shows the only wiring diagram for the component.fuse 2 fuse 19 audio, which is found in the car Isuzu Amigo II (1998-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 2 fuse 19 audio (1 of 1)
10 1 HONDA ISUZU
2 9 ISUZU HONDA
BLK WIRE
BLU WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) (1999) (1998)
FUSE 2 FUSE 19 AUDIO
GRN WIRE
HOT IN ACC OR ON
ISUZU HONDA 8 5
LEFT POWER MIRROR
LEFT RIGHT
LEFT/RIGHT
MIRROR CONTROL SWITCH
MIRROR SELECTOR SWITCH
POWER MIRROR INTERNAL SWITCH POSITIONS
PPL
RED WIRE
RED/YEL WIRE
RIGHT LEFT
RIGHT POWER MIRROR
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH 4
UP/ DOWN LEFT/ RIGHT
UP/DOWN
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> FUSE 2 FUSE 19 AUDIO
