Isuzu Amigo II (1998-2000) fuel pump relay ecm or pcm main relay Wiring diagram
This page shows the only wiring diagram for the component.fuel pump relay ecm or pcm main relay, which is found in the car Isuzu Amigo II (1998-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel pump relay ecm or pcm main relay (1 of 1)
3.2L ENGINE
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BRAIDED WIRE
BRAIDED WIRE BRAIDED WIRE
BRAIDED WIRE THROTTLE POSITION SENSOR SHIELD
CAMSHAFT POSITION SENSOR
CAMSHAFT POSITION SENSOR SHIELD
CAMSHAFT POSITION SENSOR SHIELD CRANKSHAFT POSITION SENSOR SHIELD
COIL
COIL COIL
CRANKSHAFT POSITION SENSOR
CRANKSHAFT POSITION SENSOR SHIELD
CRANKSHAFT POSITION SENSOR SHIELD CAMSHAFT POSITION SENSOR SHIELD
DATA LINK CONNECTOR
ECM MAIN RELAY
ENGINE CONTROL MODULE
ENGINE OR POWERTRAIN CONTROL MODULE
FUEL PUMP RELAY
FUEL PUMP RELAY ECM OR PCM MAIN RELAY
FUSE/RELAY BOX
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR 1 SHIELD
HEATED OXYGEN SENSOR 2 SHIELD HEATED OXYGEN SENSOR 3 SHIELD
HEATED OXYGEN SENSOR 4 SHIELD
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 4 IGNITION COIL 6
IGNITION COIL 5 IGNITION COIL 3
IGNITION CONTROL MODULE
KNOCK SENSOR SHIELD
MASS AIRFLOW SENSOR
MASS AIRFLOW SENSOR SHIELD
RED WIRE
SENSOR GROUND SHIELD
SHIELD
THROTTLE POSITION SENSOR
THROTTLE POSITION SENSOR SHIELD
THROTTLE POSITION SENSOR SHIELD CRANKSHAFT POSITION SENSOR SHIELD
TRANSMISSION SPEED SENSOR SHIELD
WHT WIRE
Go to component -> Ground distribution circuit (2 of 4) -> FUEL PUMP RELAY ECM OR PCM MAIN RELAY
