Isuzu Amigo II (1998-2000) engine control module or powertrain control module (below center of dash) wiring diagram
This page shows the only wiring diagram for the component.engine control module or powertrain control module (below center of dash), which is found in the car Isuzu Amigo II (1998-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
engine control module or powertrain control module (below center of dash) wiring diagram (1 of 1)
BLK WIRE
BLK/RED WIRE
DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
DEFOGGER
DEFOGGER RELAY CONTROL
DEFOGGER REQUEST INPUT
ENGINE CONTROL MODULE OR POWERTRAIN CONTROL MODULE (BELOW CENTER OF DASH)
FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT)
G-12 ISUZU
G-9 ISUZU
GRN WIRE
GRN/RED WIRE
HONDA
HONDA PASSPORT, ISUZU RODEO
HONDA REAR WINDOW DEFOGGER
HOT AT ALL TIMES
HOT IN ON
ISUZU
LEFT POWER MIRROR
LT GRN WIRE
MAIN FUSE
MIRROR DEFOGGER FUSE
ON INDICATOR
PNK WIRE
REAR DEFOGGER FUSE
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW DEFOGGER SWITCH LIGHT
REAR WIPER, WASHER FUSE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT POWER MIRROR
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Defogger circuit -> ENGINE CONTROL MODULE OR POWERTRAIN CONTROL MODULE (BELOW CENTER OF DASH)
