Isuzu Amigo II (1998-2000) backup/ turn light fuse Wiring diagrams

This page contains all the electrical diagrams for the component. backup/ turn light fuse, in which he is found in the car Isuzu Amigo II (1998-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram backup/ turn light fuse (1 of 3)

Wiring diagram backup/ turn light fuse for Isuzu Amigo II (1998-2000) (1 of 3)

Get access

A/C FUSE BACKUP/ TURN LIGHT FUSE BLK WIRE BLK/YEL WIRE BLOWER FUSE BLOWER MOTOR (BELOW RIGHT SIDE OF DASH) BLOWER RESISTOR (BEHIND GLOVE BOX, ON PLENUM) BLU WIRE BRN WIRE DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) ENGINE IG FUSE EVAPORATOR TEMPERATURE SENSOR FAN CONTROL SWITCH FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT) GRN WIRE GRN/BLK WIRE GRN/RED WIRE HEATER-A/C CONTROL PANEL HEATER-A/C RELAY HOT AT ALL TIMES HOT IN ON HOT IN ON OR START ILLUM J/C LT GRN WIRE MAIN FUSE NCA WIRE OFF ORG/ WIRE RED WIRE THERMO FUSE WHT WIRE YEL WIRE

Go to component -> 2.2l, manual a/c circuit (2 of 2) -> BACKUP/ TURN LIGHT FUSE

Wiring diagram backup/ turn light fuse (2 of 3)

Wiring diagram backup/ turn light fuse for Isuzu Amigo II (1998-2000) (2 of 3)

Get access

1995 VFTC BACKUP/ TURN LIGHT FUSE BLK WIRE BLOWER FUSE BLOWER MOTOR (BELOW RIGHT SIDE OF DASH) BLOWER RESISTOR (BEHIND GLOVE BOX, ON PLENUM) THERMO FUSE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE DASH FUSE BOX (BEHIND DASH, LEFT OF STEERING COLUMN) FAN CONTROL SWITCH FUSE/ RELAY BOX (ON RIGHT SIDE OF ENGINE COMPART- MENT) FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT) FUSE/RELAY BOX (ON RIGHT SIDE OF ENGINE COMPARTMENT) MAIN FUSE GRN WIRE HEATER CONTROL PANEL HEATER RELAY HOT AT ALL TIMES HOT IN ON ILLUM J/C LT GRN WIRE NCA WIRE OFF ORG/ WIRE RED WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE

Go to component -> Heater circuit -> BACKUP/ TURN LIGHT FUSE
