Car Wiring Diagrams for Rear sonar circuit for Infiniti QX80 I facelift 3 (2020-2024)

A/T ASSEMBLY (RIGHT SIDE OF TRANSMISSION) BACKUP LP RLY BLK WIRE BLU WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FRT SENS GND FUSE 4 FUSE BLOCK (J/B) GRN WIRE GRY/BLU WIRE HOT W/ IGNITION RELAY 1 ENERGIZED IGN SIG JOINT CONNECTOR LEFT FRONT CENTER SENSOR LEFT FRONT CORNER SENSOR LEFT REAR CENTER SENSOR LEFT REAR CORNER SENSOR LH FRT CEN SENS SIG LH FRT CORN SENS SIG LH RR CEN SENS SIG LH RR CORN SENS SIG NCA WIRE PNK WIRE RED WIRE RH FRT CEN SENS SIG RH FRT CORN SENS SIG RH RR CEN SENS SIG RH RR CORN SENS SIG RIGHT FRONT CENTER SENSOR RIGHT FRONT CORNER SENSOR RIGHT REAR CENTER SENSOR RIGHT REAR CORNER SENSOR RR SENS GND SHIELD SONAR CONTROL UNIT (LEFT SIDE OF DASH) TCM WHT WIRE YEL WIRE
