Infiniti QX80 I facelift 3 (2020-2024) v-can-l unified meter v-can-h control unit Wiring diagram
This page shows the only wiring diagram for the component.v-can-l unified meter v-can-h control unit, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram v-can-l unified meter v-can-h control unit (1 of 1)
A/T ASSEMBLY (RIGHT SIDE OF TRANSMISSION)
ACCELERATOR PEDAL ACTUATOR/ ACCELERATOR PEDAL POSITION SENSOR
ASCD STEERING SW
ASCD STEERING SWITCH
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
CAN COMMUNICATION LINE (CAN-H)
CAN COMMUNICATION LINE (CAN-L) STOP LAMP SW
CAN L
CAN-H
CANCEL SWITCH
CLOSE
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
ELECTRIC THROTTLE CONTROL ACTUATOR
FUSE 64
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
HOT AT ALL TIMES
INPUT SPEED SENSOR 1
INPUT SPEED SENSOR 2
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
JOINT CONNECTOR
MAIN (ON/OFF) SWITCH
NCA WIRE
ORG/ WIRE
OUTPUT SPEED SENSOR
PNK WIRE
PNK/BLU WIRE
PPL/RED WIRE
RED WIRE
RED/YEL WIRE
RESUME/ACCEL SWITCH
SENS GND
SENS PWR SPLY
SENSOR 1
SENSOR 2
SET/COAST SWITCH
STOP LAMP SWITCH
TCM
THROTTLE CONTROL MOTOR
THROTTLE CONTROL MOTOR RELAY
THROTTLE CTRL MTR (CLOSE)
THROTTLE CTRL MTR OPEN
THROTTLE CTRL MTR PWR SPLY
THROTTLE CTRL MTR RLY
THROTTLE POSITION SENSOR
TRANSMISSION RANGE SWITCH
V-CAN-L UNIFIED METER V-CAN-H CONTROL UNIT
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Cruise control circuit -> V-CAN-L UNIFIED METER V-CAN-H CONTROL UNIT
