Infiniti QX80 I facelift 3 (2020-2024) trailer accessory pre-wire connector Wiring diagrams
This page contains all the electrical diagrams for the component. trailer accessory pre-wire connector, in which he is found in the car Infiniti QX80 I facelift 3 (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trailer accessory pre-wire connector (1 of 2)
AROUND VIEW MONITOR CONTROL UNIT
AV CONTROL UNIT
BACKUP
BACKUP LAMP RELAY
BACKUP LAMP RLY
BLK WIRE
BLU WIRE
FUSE 38
FUSE 55
FUSE 85
FUSE, FUSIBLE LINK BLOCK
FUSE, FUSIBLE LINK HOLDER 5
FUSE, FUSIBLE LINK, RELAY BOX
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
JOINT CONNECTOR
LEFT REAR COMBINATION LAMP (BACK DOOR SIDE)
NCA WIRE
PNK REV SIG WIRE
PNK WIRE
PPL
RED WIRE
RED/YEL WIRE
REV SIG
RIGHT REAR COMBINATION LAMP (BACK DOOR SIDE)
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH 4
TCM
TRAILER ACCESSORY PRE-WIRE CONNECTOR
TRANSMISSION RANGE SWITCH A/T ASSEMBLY
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Backup lamps circuit -> TRAILER ACCESSORY PRE-WIRE CONNECTOR
Wiring diagram trailer accessory pre-wire connector (2 of 2)
BACKUP LAMPS CIRCUIT
BATTERY TERMINAL W/ FUSIBLE LINK
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
ELECTRIC BRAKE ACCESSORY PRE-WIRE CONNECTOR
EXTERIOR LAMPS CIRCUIT
FUSE 47
FUSE 55
FUSE 7
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK
FUSE, FUSIBLE LINK, RELAY BOX
FUSIBLE LINK F
FUSIBLE LINK K
FUSIBLE LINK N
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LEFT TRAILER TURN SIGNAL LAMP RELAY
PNK WIRE
PPL
RED WIRE
RED/GRN WIRE
RIGHT TRAILER TURN SIGNAL LAMP RELAY
STOP LAMP SWITCH
TAIL LAMP RELAY
TRAILER ACCESSORY PRE-WIRE CONNECTOR
TRAILER IND
UNIFIED METER
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Trailer tow circuit (2 of 2) -> TRAILER ACCESSORY PRE-WIRE CONNECTOR
