Infiniti QX80 I facelift 3 (2020-2024) tel antenna sig Wiring diagram

ACC PWR SPLY ACC PWR SPLY PPL ACC OUTPUT AV COMM SIG (H) AV COMM SIG (L) GND AV CONTROL UNIT (CENTER OF DASH OF DASH) BATT PWR SPLY BLK WIRE BLK/LT BLU WIRE BLU WIRE BRN WIRE CAN-H PNK CAN-L WIRE COMPUTER DATA LINES SYSTEM FUSE 19 FUSE 35 FUSE 4 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK BLOCK GPS ANTENNA GPS ANTENNA SIG GRN WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED IGN SIG LT BLU WIRE MICROPHONE MICROPHONE SIG MICROPHONE VCC (PINS: 19 TO 25 NOT USED) 26 MODE CHANGE SIG NCA WIRE ORG/ WIRE PNK SOUND SIG (+) WIRE PNK WIRE PPL PPL/WHT WIRE RED WIRE SHIELD SIG SOS CALL SW SIG SOS SW LED SIG SOUND SIG (-) SOUND SIG (-) SOS CALL SW SIG TCU (RIGHT SIDE OF DASH) TEL ANTENNA TEL ANTENNA SIG TELEMATICS ANTENNA TELEMATICS SWITCH (IN OVERHEAD CONSOLE) USB D+ SIG USB V BUS SIG VCC WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
