Infiniti QX80 I facelift 3 (2020-2024) rh frt corn sens sig Wiring diagram
This page shows the only wiring diagram for the component.rh frt corn sens sig, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rh frt corn sens sig (1 of 1)
A/T ASSEMBLY (RIGHT SIDE OF TRANSMISSION)
BACKUP LP RLY
BLK WIRE
BLU WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
FRT SENS GND
FUSE 4
FUSE BLOCK (J/B)
GRN WIRE
GRY/BLU WIRE
HOT W/ IGNITION RELAY 1 ENERGIZED
IGN SIG
JOINT CONNECTOR
LEFT FRONT CENTER SENSOR
LEFT FRONT CORNER SENSOR
LEFT REAR CENTER SENSOR
LEFT REAR CORNER SENSOR
LH FRT CEN SENS SIG
LH FRT CORN SENS SIG
LH RR CEN SENS SIG
LH RR CORN SENS SIG
NCA WIRE
PNK WIRE
RED WIRE
RH FRT CEN SENS SIG
RH FRT CORN SENS SIG
RH RR CEN SENS SIG
RH RR CORN SENS SIG
RIGHT FRONT CENTER SENSOR
RIGHT FRONT CORNER SENSOR
RIGHT REAR CENTER SENSOR
RIGHT REAR CORNER SENSOR
RR SENS GND
SHIELD
SONAR CONTROL UNIT (LEFT SIDE OF DASH)
TCM
WHT WIRE
YEL WIRE
Go to component -> Rear sonar circuit -> RH FRT CORN SENS SIG
