Infiniti QX80 I facelift 3 (2020-2024) ppl cooling fan speed Wiring diagram
This page shows the only wiring diagram for the component.ppl cooling fan speed, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl cooling fan speed (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
CAN COMM LINE PNK CAN COMM LINE WIRE
COMPUTER DATA LINES SYSTEM
ECM (RIGHT SIDE OF ENGINE COMPT)
ELECTRICALLY CONTROLLED COOLING FAN COUPLING
ENG COOL TEMP SENS 1
ENG COOL TEMP SENS 2
ENGINE COOLANT TEMPERATURE SENSOR 1
ENGINE COOLANT TEMPERATURE SENSOR 2
FUSE 72
FUSE, FUSIBLE LINK HOLDER 1
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
IGNITION RELAY
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT BLU WIRE
ORG/BLK WIRE
PNK WIRE
PPL
PPL COOLING FAN SPEED
RED WIRE
REFRIGERANT PRESS SENS
REFRIGERANT PRESSURE SENSOR
SENS GND
SENS PWR SUPPLY
WHT/BLU WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Cooling fan circuit -> PPL COOLING FAN SPEED
