Infiniti QX80 I facelift 3 (2020-2024) passenger side front seat belt buckle switch Wiring diagram
This page shows the only wiring diagram for the component.passenger side front seat belt buckle switch, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side front seat belt buckle switch (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
CENTER THIRD SEAT BELT BUCKLE SWITCH
COMBINATION SWITCH (SPIRAL CABLE)
DRIVER AIR BAG MODULE
DRIVER SIDE FRONT SEAT BELT BUCKLE SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
LEFT FRONT DOOR SATELLITE SENSOR
LEFT SEAT BELT PRE-TENSIONER
LEFT THIRD SEAT BELT BUCKLE SWITCH
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER SIDE FRONT SEAT BELT BUCKLE SWITCH
PPL
RED WIRE
RIGHT FRONT CURTAIN AIR BAG MODULE
RIGHT LAP PRE-TENSIONER
RIGHT REAR SATELLITE SENSOR
RIGHT REAR SEAT BELT PRE-TENSIONER
RIGHT THIRD SEAT BELT BUCKLE SWITCH
SHIELD
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> PASSENGER SIDE FRONT SEAT BELT BUCKLE SWITCH
