Infiniti QX80 I facelift 3 (2020-2024) oil press/ level ind Wiring diagram
This page shows the only wiring diagram for the component.oil press/ level ind, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil press/ level ind (1 of 1)
120 KM/H IND
ABS IND.
AIR BAG IND
AUTO HI-LOW/ ADB IND
BELT IND
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
BUZZER
C-ENG IND
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEMS
DIPPED BEAM IND
DOOR LOCKS, ANTI-THEFT SYSTEMS
E-PKB (R) IND
E-PKB (Y) IND
ECO IND
ECO PEDAL IND
ELECTRONIC POWER STEERING, POWER TOPS SYSTEMS
EPS/SBW IND
EV IND
FCA IND
FILTER IND
FR-FOG IND
FUEL GAUGE
FUEL LEVEL SENSOR UNIT, FUEL PUMP
FUSE 10
FUSE 19
FUSE 3
FUSE 6
FUSE BLOCK (J/B)
GRN/WHT WIRE
GROW IND
GRY WIRE
GRY/RED WIRE
HDC IND
HEADLIGHTS SYSTEM
HEV BRAKE IND
HEV SYSTEM FAIL IND
HI-BEAM IND
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
HOT W/ IGNITION RELAY 1 ENERGIZED
IGN
ILL (DIAL) IND
ILL (DISPLAY) IND
ILL (NEEDLE) IND
ILL (RING) IND
LEFT TURN IND
LT BLU WIRE
LT GRN WIRE
MASTER (RED) IND WIRE
MASTER (YEL) IND WIRE
OIL PRESS/ LEVEL IND
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
PARKING BRAKE SWITCH
PNK WIRE
PNK/BLU WIRE
POP UP HOOD IND
POSITION LAMP IND
PPL
PPL/WHT WIRE
READY IND
RED WIRE
RED/YEL WIRE
RIGHT TURN IND
RR-FOG IND
SECURITY IND
SLIP IND
SPEEDOMETER
SSA (GREEN) IND
SSA (WHITE) IND
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TPMS IND
TRAILER IND
TRANSMISSIONS SYSTEM
UNIFIED METER CONTROL UNIT
VDC OFF IND
VSP OFF IND
WASHER LEVEL SWITCH
WATER TEMPERATURE GAUGE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/PPL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> OIL PRESS/ LEVEL IND
