Infiniti QX80 I facelift 3 (2020-2024) integrated homelink transceiver Wiring diagram
This page shows the only wiring diagram for the component.integrated homelink transceiver, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram integrated homelink transceiver (1 of 1)
AUTO ANTI-DAZZLING INSIDE MIRROR
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
DRIVER SIDE DOOR MIRROR
FUSE 4
FUSE 6
FUSE BLOCK (J/B)
GRY WIRE
GRY/BLU WIRE
HIGH BEAM ASSIST CONTROL MODULE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
IGN
INTEGRATED HOMELINK TRANSCEIVER
LT BLU WIRE
PASSENGER SIDE DOOR MIRROR
RED WIRE
SIG
YEL WIRE
Go to component -> Power mirrors circuit, w/o smart rear view mirror -> INTEGRATED HOMELINK TRANSCEIVER
