Infiniti QX80 I facelift 3 (2020-2024) backward pnk strg sens vcc Wiring diagram
This page shows the only wiring diagram for the component.backward pnk strg sens vcc, which is found in the car Infiniti QX80 I facelift 3 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backward pnk strg sens vcc (1 of 1)
AUTOMATIC DRIVE POSITIONER CONTROL UNIT
BACKWARD
BACKWARD PNK STRG SENS VCC WIRE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
BWD
CHANGE OVER SWITCH
DOWNWARD
FUSE 10
FUSE 19
FUSE BLOCK (J/B)
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
INDICATOR 1
INDICATOR 2
LEFTWARD
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MEM 1 SET
MEM 2
MEMORY
MIR MTR DN RH (LH) DOWNWARD
MIR MTR LEFT (LH)
MIR MTR LEFT (RH)
MIR MTR UP (LH)
MIR MTR UP (RH)
MIR SENS LEFT, RIGHT (LH)
MIR SENS LEFT, RIGHT (RH)
MIR SENS UP DN (LH) FORWARD PNK WIRE
MIR SENS UP DN (RH)
MIRROR SWITCH
OFF
OFF OFF
OPEN/CLOSE SWITCH
ORG/ WIRE
ORG/BLU WIRE
PNK WIRE
PNK/BLU WIRE
POWER WINDOW MAIN SWITCH (DOOR MIRROR REMOTE CONTROL SWITCH)
PPL
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHTWARD
RX/TX
SEAT MEMORY SWITCH
SELECT LH
SELECT RH
SENS GND
SENS PWR PPL MIR MTR DN RIGHT (RH)
TELESCOPIC SWITCH
TILT SWITCH
TILT, TELESCOPIC SWITCH
UPWARD
UPWARD/FRONTWARD
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Memory systems circuit (1 of 3) -> BACKWARD PNK STRG SENS VCC WIRE
