Infiniti QX80 I facelift 3 (2020-2024) a/t shift select pwr sply Wiring diagrams
This page contains all the electrical diagrams for the component. a/t shift select pwr sply, in which he is found in the car Infiniti QX80 I facelift 3 (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/t shift select pwr sply (1 of 2)
2346 BRAKE SOLENOID VALVE
A/T ASSEMBLY (RIGHT SIDE OF TRANSMISSION)
A/T FLUID TEMPERATURE SENSOR
A/T SHIFT SELECT PWR SPLY
A/T SHIFT SELECTOR
ANTI- INTERLOCK SOLENOID VALVE
ATF PRESSURE SENSOR
BATT (F/L)
BATT FUSE
BCM (BODY CONTROL MODULE)
BLK WIRE
BLK/LT BLU WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
CAN-H
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DIRECT CLUTCH SOLENOID VALVE
DOOR LOCKS, ANTI-THEFT SYSTEMS
FRONT BRAKE SOLENOID VALVE
FUSE 10
FUSE 3
FUSE 38
FUSE 55
FUSE 6
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK K
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HIGH, LOW REVERSE CLUTCH SOLENOID VALVE LOW BRAKE SOLENOID VALVE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
HOT W/ IGNITION RELAY ENERGIZED
IGN PWR SPLY
IGN PWR SPLY BACKUP LAMP RLY CAN-L
INPUT CLUTCH SOLENOID VALVE
INPUT SPEED SENSOR 1
INPUT SPEED SENSOR 2
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
JOINT CONNECTOR
K LINE
LINE PRESSURE SOLENOID VALVE
LT BLU WIRE
LT GRN WIRE
MANUAL AUTO
MODE SELECT SWITCH
NCA WIRE
ORG/ WIRE
OUTPUT SPEED SENSOR
PARK POSITION SWITCH
PNK WIRE
POSITION SELECT SWITCH
PPL
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SELECTOR LEVER POSITION INDICATOR
SHIFT INTERLOCK SYSTEM
SHIFT LOCK SOLENOID
SHIFT POSITION SWITCH
SNOW MODE/ TOW MODE/ VDC OFF SWITCH ASSEMBLY
START RLY
STARTING/ CHARGING SYSTEM
TCM
TORQUE CONVERTER CLUTCH SOLENOID VALVE
TOW MODE SWITCH
TRANSMISSION RANGE SWITCH
TRANSMISSION RANGE SWITCH ASSEMBLY
UNIFIED METER CONTROL UNIT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> A/t circuit -> A/T SHIFT SELECT PWR SPLY
Wiring diagram a/t shift select pwr sply (2 of 2)
A/T SHIFT SELECT PWR SPLY
A/T SHIFT SELECTOR
BCM (BODY CONTROL MODULE)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
CAN-H
COMPUTER DATA LINES SYSTEM
FUSE 3
FUSE 7
FUSE BLOCK (J/B)
FUSE, FUSIBLE LINK, RELAY BOX
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY 1 ENERGIZED
LOW SIDE PUSH LED
PARK POSITION SWITCH
RED WIRE
RED/BLK WIRE
REMOTE ENG ST
REMOTE ENGINE START RELAY
SELECTOR LEVER POSITION INDICATOR
SHIFT LOCK SOLENOID
SHIFT POSITION SWITCH
STOP LAMP SWITCH
STOP LP SW 1 PNK CAN-L WIRE
Go to component -> Shift interlock circuit -> A/T SHIFT SELECT PWR SPLY
